Nano Carbon (Super Eclipse) Environmentally Friendly Introduction to Hole Metallization
1. PRODUCT CHARACTERISTICS
2. STANDARD OPERATING PROCEDURES FOR THE NANOCARBON PROCESS
Grind the board —— clean the whole hole —— overflow water washing —— nano carbon one —— hot air blow dry —— pre-micro-etching —— hot air blow dry —— nano carbon two —— overflow water washing —— whole hole —— micro-etching —— overflow water washing —— hot air blow dry —— finished metallization —— to do multilayer board,it needs to be configured with horizontal or vertical debinding, and then enter the nano carbon line.
3. COMPARISON OF NANOCARBON PROCESS ADVANTAGES
Compared with the traditional PTH process, nanocarbon process has many advantages:
1) Shortening of the process and significant increase in production efficiency
2) Easy to control the process, simple operation, and simple maintenance of the solution
3) Excellent stability and long service life, significantly reducing the cost of use.
4) No formaldehyde and other harmful substances, green environmental protection
Compared with traditional nano carbon products, our nano carbon products have many advantages:
1) The same length of the production line using nano carbon, the use of our synthetic nano carbon, production capacity increased by 1-2 times, a line when the two used.
2) Saving about 50% of water and electricity.
3) Waste water discharge is reduced by about 50%.
4) It can be applied to various materials and thickness of hard board, soft board and soft and hard combination board.
5) For the slot hole boards and multilayer boards which have higher requirements for the bonding force of the copper plating layer on the hole wall, the bonding force of the hole wall reaches or exceeds the chemically immersed copper process after special treatment.
Our products are sold all over the world, you can rest assured.
